ClareOne Zone Profiles Tech Bulletin

Zone Profiles are introduced with the release of ClareOne v2.0. Zone Profiles provide the dealer/installer with flexibility to customize ClareOne sensors and their behavior on ClareOne.

Summary

A Zone Profile is a collection of advanced properties that are applied to each sensor (aka zone types), every sensor must be assigned a zone profile.

Basic zone settings are not part of zone profiles and can be changed independent of the selected zone profile. In most cases, the default zone profiles will provide the necessary configuration required for a zone.

For more advanced configuration and for special use cases, each zone profile setting can be edited in the Advanced Settings section of the sensor settings. If one or more advanced settings are changed, and the collection of settings do not equal the settings for an included Zone Profile, "Custom" will be displayed as the selected Zone Profile name. The selected Zone Profile can then be changed at any time from Custom to one of the provided Zone Profiles available for the sensor type.

Profile Properties

When adding or editing a zone, there are two types of settings that can be used to configure the zone - Basic Settings and Advanced Settings:

Basic Settings

Basic settings include the following (note, not all settings are exposed for all sensor types):

Voice Annunciation

Enabled –Zone annunciates the name of the sensor which was opened/activated.

Disabled – Zone does not annunciate the name of the sensor which was opened/activated.

Open Chime

Enabled – Chime sounds when a sensor is opened/activated.

Disabled – Chime does not sound when a sensor is opened/activated.

Cross Zoning

Enabled - Links 2 or more sensors together. If one of the sensors in the “Cross Zone” is tripped and another sensor in that cross zone is tripped within the set time, an alarm is triggered.

Disabled – (Default) Cross zoning is not active.

Low Battery Detection

Enabled – (Default) Low battery warnings from sensor are displayed on ClareOne and in application with a battery icon on the zone list.

Disabled – Low battery warnings from sensor are not displayed on ClareOne or in application.

Normally Open

Enabled – Changes the external contact detection from normally closed to normally open.   Normally open contacts are not touching when sensor is in it’s not faulted state. Closed when in their faulted state.

Disabled – (Default) External contact detection is set to normally closed. Normally open contacts are touching when sensor is in it’s not faulted state. Open when in their faulted state.

Note: Applies only to sensors with external contacts.

Advanced Settings

Advanced settings which can be applied to all sensor types. Each setting has a default value depending on the sensor type. The following list defines each setting available in Advanced settings.

Entry/Exit Delay

Entry Delay - The time allowed after opening the associated sensor before and alarm is tripped.

Exit Delay – The time allowed to exit before the ClareOne panel is armed.

Active in Arm Stay

Enabled – Zone is active when ClareOne is Armed Stay.

Disabled – Zone is not active when ClareOne is Armed Stay.

Active in Arm Away

Enabled – Zone is active when ClareOne is Armed Away.

Disabled – Zone is not active when ClareOne is Armed Away.

Active in Disarm

Enabled – Zone is active when ClareOne is not armed. The zone follows Active in Arm Stay/Away settings when the panel is armed.

Disabled – Zone follows Active in Arm Stay and Arm Away settings.

Follower

Enabled – Zone will not trip or report alarm during entry and exit delays.

Disable – Zone will trip and report alarm during entry and exit delays if not cancelled first.

Alarm Type

The type of alarm associated with the zone. Used to display alarm type on ClareOne and Clare App.

Available Alarm Types:

Auxiliary

Carbon Monoxide

Fire Panic

High Temperature

Intrusion

Low Temperature

Panic

Silent Auxiliary

Silent Panic

Water Level

Siren Type

The type of siren associated with the zone.

None

Intrusion

Low Level

T3

T4

Require Restoral Event

Enabled – Zone generates a restoral event when it transitions from tripped (alarm state) to normal.

Disabled – Zone does not generate a restoral event when it transitions from tripped (alarm state) to normal.

Report Code

The reporting code used for alarms and restoral of this zone, using Contact ID reporting codes.

000 - Local Alarm

151 - Gas Detection

100 - Medical

152 - Refrigeration

101 - Auxiliary Panic

153 - Loss of Heat

110 - Fire

154 - Water Leakage

111 - Smoke

158 - High Temperature

114 - Heat

159 - Low Temperature

115 - Fire Panic

162 - Carbon Monoxide Detection

120 - Police Panic

300 - System Trouble

122 - Silent Panic

333 - Expansion Module Failure

123 - Audible Panic

334 - Repeater Failure

130 - Intrusion Alarm

337 - Expansion Module DC Loss

131 - Perimeter

338 - Expansion Module Low Battery

132 - Interior

339 - Expansion Module Reset

133 - 24 Hour Burglary

341 - Expansion Module Tamper

134 - Entry/Exit

342 - Expansion Module AC Loss

135 - Day/Night

350 - Communication Trouble

136 - Outdoor

601 - Manual Trigger Test

144 - Zone Tamper

641 - Senior Watch Trouble

145 - Expansion Module Tamper

642 - Latch-Key Supervision

150 - 24 Hour Non-Burglary

Tamper Alarm Active

Enable – When a zone is tampered while in an armed state, at tamper alarm will be generated. When not armed a tamper trouble is generated.

Disabled – When a zone is tampered while in an armed state, at tamper alarm will not be generated. When armed or not armed, a tamper trouble is generated.

Delay Alarm Report

Enabled – Alarm delivery is delayed (configurable on ClareOne panel settings) after an alarm is tripped to allow time to cancel it.

Disabled – Alarm delivery is immediate after an alarm is tripped. Should be used with all Fire and Life Safety zones.

Zone Profiles Applications and Default Settings

Advanced settings which can be applied to all sensor types. Each setting has a default value depending on the sensor type. The following list defines each setting available in Advanced settings.

Table 1
